Your drawings know the work. Let AI read them.
Upload a mechanical drawing. DrawingPhin turns it into ballooned features, FAIR forms, and review findings in minutes.
See DrawingPhin in action
These are not recordings. Open the real result and look around it yourself.
Live resultFrom upload to a ballooned FAIR
It finds the tolerance rule in the notes — and applies it, band by band.
Export AS9102 Form 3 — with the marked-up print
One zip. The numbers on the sheet match the balloons.
DFM review, in the same pass
Findings with evidence and a place on the print. Export as PDF or Word.
See what happens after upload
Upload once. Get ballooned results in minutes.
- 1
Upload a drawing
- 2
AI identifies dimensions, tolerances, GD&T and notes
- 3
Ballooned characteristics are generated
- 4
AS9102 FAIR is prepared, with optional DFM review
What you get from your first upload
Every output points back to the drawing you uploaded.
AI ballooning
AI detects and numbers dimensions, tolerances and GD&T — refine, add or edit by hand anytime.
AS9102 Form 3
FAIR forms
Export AS9102 / medical FAI / PPAP templates in one click, features auto-filled.
DFM review
A rule engine + AI flag missing tolerances, materials and conflicting requirements — marked on the drawing.
Source-linked results
Each extracted characteristic points back to its place on the original drawing.
Built for engineering data
Designed for real drawing workflows, with clear handling of your files and outputs.
No model training
Your drawings are not used to train AI models.
Encrypted storage and transfer
Files and results are encrypted in transit and at rest.
Your drawings stay yours
DrawingPhin claims no ownership of your drawings, results or exports.
Source-linked outputs
Every characteristic is traceable back to its source on the drawing.
Calculate your monthly FAIR savings
See the real impact of automating drawings and FAIR compliance.
Manual ballooning + FAIR + review
just $2/drawing
You save
$1,460/month
At about $2 per drawing, the real savings come from labor, rework and delivery time.
Frequently asked questions
What file types can I upload?
PDF, DXF and image files, including scanned drawings. DWG needs to be exported to PDF or DXF first.
What do I get after analysis?
Ballooned characteristics on your drawing, an AS9102 / medical FAI / PPAP export filled from them, and — when you select it — DFM review findings.
Is DFM review required?
No. FAIR generation works on its own; DFM review is optional and needs a Standard or Pro plan.
How is my drawing data handled?
Your drawings are not used to train AI models, and files are encrypted in transit and at rest. See the Engineering Data & AI Policy for details.
